Output 3KW 24V Stable Hybrid Solar Inverter 90A MPPT Controller Inverter Integrated Control with WIFI

1 Piece
MOQ
$375.00(1 - 49 Pieces) $360.00(>=50 Pieces)
preço
Output 3KW 24V Stable Hybrid Solar Inverter 90A MPPT Controller Inverter Integrated Control with WIFI
Características Galeria Descrição de produto Peça umas citações
Características
Especificações
Customized support: yes
Model Number: MPS-V PLUS 3.5KW
Type: DC/DC Converters, DC/AC Inverters
Output Type: Single
Output Current: 13A
Output Frequency: 50Hz±3
Size: 44*30*10
Weight: 12KG
Mumidity: 5% to 95% Relative Humidity(Non~condensing)
Color: Customized Color
Rated power: 5500VA/5500W OR 3500VA/3500W
Input voltage range: 120-450VAC
Efficiency: High Efficiency
Feature: Stable Output
Warranty: 1 Year
Working Temperature: 0 ~55
Frequency: 50/60HZ
Frequency Range: 50 Hz/60Hz(Auto sensing)
Informação básica
Model Number: MPS-V PLUS 3.5KW
Condições de Pagamento e Envio
Supply Ability: 1000 Piece/Pieces per Month
Descrição de produto
Product Description
Mppt solar charging controller 12v 24v 48v 36v solar panel controller (12v 24v 48v automatic Identification)
MPPT (Maximum Power Point Tracking)Solar Charge Controller offer an efficient, safe, multi-stage recharging process that prolongs battery life and assures peak performance from a solar array. Each Charge Controller allows customized battery recharging.
Specification
model
IGrid VE 5.5K-48V
Maximum PV array power
5500W
Rated output power
5500W
MPPT range and working voltage
120-450VDC
Rated output voltage
220/230/240VAC
Output voltage range
184-265VAC
Rated output current
20.5A/19.6A/18.8A
efficient
up to 93%
Acceptable input voltage range
120-280VAC
Frequency Range
50Hz/60Hz (self-adaptive)
Rated output voltage
220/230/240VAC
Output waveform
Pure sine wave
Rated DC voltage
48VDC
Maximum AC charging current
60A
Maximum charging current (AC + PV)
90A
Maximum output power
5500W
Surge power
11000W
Automatic conversion time
<10ms
Parallel function
Yes
communication
USB or RS232, WIFI, generator dry contact
humidity
0~90% RH (non-condensing)
Operating temperature
0 to 50 ℃
Net weight (KG)
11.35
Gross weight (KG)
12.35
Dimensions (length x width x height) mm
295x468.6x120.2
Our Advantages
1.Supply Support
We ensures the product with good quality,sufficient quantity and diversification.
2.Quality Safety
We own professional quality management and process inspecion team.
3.Unique Design Concept
Provide the most excellent products,the most excellent products.
4.Service Team
We have a professional customer service team to answer your doubts at any time.
Company Profile
GUOMAO is a manufacturer of solar power system with well-equipped testing facilities and strong technical force.It is located in Jingjiang. GUOMAO, specialized in R&D.We are concentrated on on-grid system,off-grid system and intergrated solar system.The main products including Mono-crystalline PV panel,Poly-crystalline PV panel,Storage battery,solar charge controller,solar inverter and so on.We have our own factory to product solar mounting and PV modules.
GUOMAO has introduced advanced automatic production equipment from Germany,Italy and Japan.Our products are global and trusted by users. GUOMAO provide one-stop service for design, production, sales and installation.We are looking forward to cooperating with you sincerely.
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
1.Why choose us?
A: We are absolutely excellent quality, reasonable price, as well as the entire team to customers for a full
range of services to ensure the interests and satisfaction of customers, we always take integrity and respect as the foundation.
2.What are the price terms?
A: The prices listed are ex-factory. There may be additional shipping costs depending on the forwarder and method of
transportation. Prices may fluctuate due to changes in material cost/labor cost/exchange rate. Please consult our sales staff confirm the order.
3.How's about the packing?
A: To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
4.What are the terms of payment?
A: Telegraphic transfer 30% as deposit, before delivery telegraphic transfer 70%. We'll show you a picture of the product and packaging before you pay.
5.What's your delivery time?
A: For the products in stock, we can deliver them to you in 5-10 days. The normal lead time for mass production is 20-45 days. Specific also depends on destination port and decide.
6.How to place and pay?
A: You can contact our Sales Manager to draw up your π or Transaction Guarantee Order, or you can press the "Order Start" button on Alibaba.
